KTM 990 ADVENTURE EU User Manual

SERVICE WORK ON THE CHASSIS 82
10.9Installing the radiator guard
0
0
55
0
0
11
0
0
11
0
0
22
0
0
33
0
0
44
100639-10
– Place nuts  onto tabs  of the radiator.
– Hook radiator guard  into holes  at the bottom and swing up to the radiator.
– Mount and tighten screws .
Guideline
Remaining chassis nuts M6 15 Nm
(11.1 lbf ft)
10.10Removing the seat
100516-10
– Insert the ignition key into the seat lock.
– Turn the ignition key to position .
– Lift up the seat at the rear, pull it back and remove from above.
– Remove the ignition key.
