ELECTRICAL SYSTEM 138
– Check the turn signal to make sure it is functioning properly.
– Position the diffuser.
Info
Hook in projection at recess .
– Insert the screw and first turn it counterclockwise until it engages in the thread. Tighten
the screw slightly.
13.13Changing the tail light bulb
Note
Damage to reflector Reduced luminance.
– Grease on the lamp will evaporate due to the heat and be deposited on the reflector. Clean the lamp and keep it free of grease before
mounting.
100599-10
– Remove nuts at the bottom of the rear fender and pull out the tail light toward the
rear.
