CONTROLS 35
Combination instrument - tachometer
400916-10
The tachometer shows the engine speed in revolutions per minute.
The red marking shows the overspeed range of the engine.
Combination instrument - indicator lamps
400917-01
The indicator lamps offer additional information about the operating state of the motorcy-
cle.
Possible states
The turn signal indicator lamp flashes green simultaneously with the turn
signal – The turn signal is switched on.
The idle speed indicator lamp lights up green – The transmission is shifted
to idle.
The high beam indicator lamp lights up blue – The high beam is switched
on.
The temperature warning lamp lights up red – The coolant has reached a
critical value.
The fuel level warning lamp lights up orange – The fuel level has reached
the reserve mark. The display switches to TRIP F.
