MAINTENANCE WORK ON FRAME AND ENGINE 94

Checking the chain, rear sprocket and engine sprocket

100132-10

– Check the rear sprocket and engine sprocket for wear.

» If the rear sprocket or engine sprocket is worn:

–

Change the rear sprocket or engine sprocket. x

Info

The rear sprocket, engine sprocket and chain should always be changed

together.
