100505-10
– Hook projection of the seat into the storage compartment, lower the seat at the rear
and push it forward at the same time. The two projections must be inserted into the
frame.
– Push locking pin into the lock housing and push the back of the seat down until the
locking pin locks in place with an audible click.
– Finally, check that the seat is correctly mounted.
Fork/shock absorber
100532-10
The fork and the shock absorber offer many options of adapting the suspension to your rid-
ing style and the payload.
Info
To help you adapt the vehicle, we have summarized our findings in Table . You
can find the table under the seat.
These adjustments should be understood as a guideline and should always be the basis of
your own personal suspension adaptation. Do not change the adjustments at random or by
more than ± 40%, since otherwise the riding characteristics could deteriorate, particularly
at high speeds.
