3SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model R065
Type Canopy CAB
*Operating weight kg 4280 4425
Bucket capacity m 0.68
Engine
Manufacturer KUBOTA
Model Water-cooled V2607-DI-E3-WL
Horse power (SAE J1995) kW/rpm (HP/rpm) 36.5 / 2400 (48.9 / 2400)
Horse power (ISO 9249, SAE J1349) kW/rpm (PS/rpm) 34.8 / 2400 (47.3 / 2400)
Number of cylinders 4
Displacement cc 2615
Starter V/kW 12 / 2
Battery V/Ah 12 / 95
Dimensions
Overall length mm 5300
Overall width (without bucket) mm 1680
Overall height mm 2460 2480
Min. ground clearance mm 330
Wheel base mm 1950
Tread mm 1356
Angle of articulation Deg 40 each
Angle of oscillation Deg 8 each
Loader clearance circle mm 6770
Bucket
Hinge pin height mm 3230
Dump height (without teeth) mm 2535
Reach fully raised (without teeth) mm 780
Tipping load, straight (ISO 14397-1) kg 2825 3000
Tipping load, full turn (ISO 14397-1) kg 2475 2625
Rated operating capacity (ISO 14397-1) kg 1235 1310
Lifting capacity at ground level kN 26.2
Breakout force (ISO 14397-2) kN 36.3
Fork
Tipping load, full turn (ISO 14397-1) kg 2000 2120
Rated operating capacity (SAE J1197)
48 in. tines
kg 1200 1270
Traveling
Drive system 4 WD
Tire 12.5-18
Traveling speed
Forward km/h 0 to 20
Reverse km/h 0 to 20
Traction force kN 29.1
Auxiliary
Max. flow rate (theoretical) L/min 53.8
Max. pressure Mpa (kgf/cm ) 18.6 (190)
Others
Fuel tank L 70
Hydraulic oil tank L 39
Hydraulic oil system L 55
NOTE: The above dimensions are based on the machine with std. tires, quick coupler, standard bucket and ROPS/FOPS-canopy/cabin.
Mean value and value for use on concrete roads are given for tipping load and operating capacity.
Specifications subject to change without notice
*Operating weight: with 75 kg operator, 297 kg standard general purpose bucket and fully served.
