59PERIODIC SERVICE
BChecking hydraulic oil level
To avoid personal injury or death:
A Never open the oil port immediately after the
engine has stopped or hydraulic oil may rush
out, causing scalding.
1. Stop the machine on flat ground and lower the bucket
to the ground and roll back the bucket.
2. Check the hydraulic oil level in the oil level gauge.
3. If the oil level is between the upper and lower marks,
the amount of the oil is appropriate.
4. If the hydraulic oil level is below the bottom mark, add
oil through the oil port.
A When refilling the hydraulic oil, clean the area around
the oil port and use the same brand of oil of the same
manufacturer.
A Never mix hydraulic oils of different manufacturers.
(1) Oil level gauge
(1) Mat
(1) Bolts
(2) Cover
(1) Oil port cap
