35OPERATION OF THE MACHINE
C To move backward:
Move the direction switch backward and press the
accelerator pedal.
A When the machine begins to travel "BACKWARD", the
back buzzer starts sounding.
A The instrument panel " " goes on.
A If the hydraulic oil temperature is too low, the reserve
alarm may start sounding when switching from the
backward to the forward travel. This is not a problem.
Just make a warm-up run, and then the hydraulic oil
temperature rises, this will stop the alarm. If the alarm
still keeps sounding, contact your local dealer.
BSpeed Control Switch
2 speed control switches serve to change maximum
speed and low speed.
Press the right speed control switch and the maximum
speed is 20 km/h.
Press the left speed control switch, speed is limited to 4.6
km/h.
(1) Direction switch (B) "BACKWARD"
(1) Left speed control switch
(2) Right speed control switch
(A) 4.6 km/h
(B) 20 km/h
