CHECKS BEFORE START22
BInterior Lamp
Press the lamp itself, and the lamp lights up. Press the
lamp again to turn it off.
BWorking Light Switch
This switch is operative with the starter key in the "RUN"
position.
The switch has 3 positions. When positioned on your side,
the lights stay off. Move the switch to the first position to
turn on the front working light, and to the second position
to turn on both the front working lights and rear working
lights.
BOpening/Closing of CABIN Door
1. Unlock the CABIN door and pull the knob. Open the
CABIN door fully until fixed into place.
2. To close the CABIN door, push the release lever down
and close the door.
3. When leaving the wheel loader, always lock the door.
(1) Interior lamp
(1) Working light switch
(1) Door knob (outside)
(1) Release lever
(2) Release button
(3) Door knob (inside)
To Next Page
