Preface > About this Operation Guide
Originals and Paper Sizes
This section explains the notation used in this guide when referring to sizes of originals or paper sizes.
As with A4, B5 and Letter, which may be used either in the horizontal or vertical direction, horizontal direction is
indicated by an additional letter R in order to indicate the orientation of the original/paper.
Icons on the Touch Panel
The following icons are used to indicate originals and paper placement directions on the touch panel.
Placement direction Indicated size*
* The size of the original/paper that can be used depends on the function and source tray. For further
details, refer to the page detailing that function or source tray.
Vertical
direction
For the originals/paper, dimension Y is longer than X.
A4, B5, A5, Letter,
Statement
Horizontal
direction
For the originals/paper, dimension Y is shorter than X.
A4-R, B5-R, A5-R,
Letter-R, Statement-R
Placement
direction
Originals Paper
Vertical
direction
Horizontal
direction
Original Paper
Original Paper
