RS-232C Protocol
B-9
B.4 RS-232C Protocol
A protocol is a set of rules the computer follows in sending data to the
printer. The RS-232C parameters are stored in battery backed-up memory.
They are indicated on the status printout. They can be changed by the
FRPO (firmware reprogram) command described in the Technical
Reference provided on the CD-ROM supplied with the printer. The
parameters and their identification codes are given below.
H1: Baud rate
The factory setting is 9600 baud.
H2: Data bits
7 or 8, factory-set to 8.
H3: Stop bits
1 or 2, factory-set to 1.
H4: Parity
The factory setting is None (0 on the status printout).
Parameter value Baud rate
12 1200
24 2400
48 4800
96 9600
19 19200
38 38400
57 57600
11 115200
Parameter value Meaning
0 None
1Odd
2Even
3 Ignore

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
