Kyocera FS-1020D User Manual

Other Settings
1-55
1.6.5 Adding an Asset Number to the Printer
You can add an asset number to the printer. The asset number can only be
defined when your printer is connected to a network, and is stored by the
printer. The name and explanation are stored in the KM-NET Remote
Operation Panel utility.
1
Click the MENU button on the start-up screen.
2
The Menu dialog box appears. Select and double click on General and
then on User defined setting.
3
Click the Asset number, and enter the asset number for that item in
the text box on the right side of the screen.
4
After making the settings, click the OK button to return to the start-
up screen. The settings are changed.
User defined setting
General
Asset number
Enter the asset
number

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
