Kyocera FS-1020D User Manual

Indicators
3-14
3.3.4 Normal Indicator Display
The following displays appear during normal printer operation.
Indicator Remote Operation
Panel display
Description
Cancelling data Data inside the printer is being canceled.
The indicators light in sequence from the top, then
go off in sequence from the bottom. This process is
repeated twice.
When the printer is switched on for the first time
after the toner container is installed, (Adding
toner) also appears.
Please wait The printer is warming up and is not ready to print.
The indicators light in sequence twice from top to
bottom.
When the printer is switched on for the first time
after the toner container is installed, (Adding
toner) also appears.
Processing The printer is receiving data.
Processing The printer is processing data.
Waiting The printer is waiting for the end-of-job command
before printing the last page. Pressing the key
allows you to obtain the last page immediately.
Form Feed Timeout The printer is printing the last page after a waiting
period.
Ready The printer is ready to print.
The printer is offline. The printer stores but does
not print received data.
Sleeping The printer is in sleep mode. The indicator
flashes at 5-second intervals and all other
indicators go off. The printer wakes from Sleep
mode whenever a key on the operator panel is
pressed, the cover is opened or closed, or data is
received. The printer then warms up and goes
online. (You can set the amount of time before the
printer enters sleep mode from the KM-NET
Remote Operation Panel utility.)
Table 3-6

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
