Kyocera FS-1020D User Manual

Cleaning the Printer
2-6
2.2 Cleaning the Printer
To avoid print quality problems, the interior of the printer must be cleaned
with every toner container replacement.
Cleaning should be done from time to time to avoid print quality
problems.
2.2.1 Printer Interior
To avoid print quality problems due to paper dust and debris, clean the
interior of the printer in the following manner.
1
Open the printer’s top and front covers.
Figure 2-8
2
Lift the process unit together with the toner container out of the
printer.
The drum in the process unit is sensitive to light. Never expose the drum
even to normal office lighting (500 lux) for more than five minutes.
Figure 2-9
Note
Top Cover
Front Cover
Note
Process Unit

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
