Print Quality Problems
3-3
3.2 Print Quality Problems
As the following table shows, there are many possible causes of print
quality problems, such as blank output as. The troubleshooting procedure
for each type of problem is explained below. If you still can not solve the
problem, contact your Kyocera Mita dealer.
Printed Results Corrective Action
All-black printout Contact your Kyocera Mita dealer.
Dropouts, horizontal streaks, stray dots Clean the charger wire.
Open the printer’s top and front covers. Remove the
process unit from the printer and slide the charger knob
back and forth to clean the charger wire.
(See Chapter 2)
Black or white vertical streaks Check the operator panel.
When the (toner) indicator flashes, install a new
toner kit. Clean the printer after replacement.
(See Chapter 2)
Clean the charger wire.
Open the printer’s top and front covers. Remove the
process unit from the printer and slide the charger knob
back and forth to clean the charger wire.
(See Chapter 2)
Check the position of the charger cleaner knob.
Open the printer’s top and front covers. Remove the
process unit from the printer. Make sure the charger
cleaner knob is restored to its home position.
(See Chapter 2)
Change the corresponding custom paper type
setting.
When selecting the settings for the custom paper type
under the Custom Paper Type Settings, be sure to select
Normal 1 as the corresponding weight in the KM-NET
Remote Operation Panel. (See section 1.4.8 Custom
Paper Type Settings on page 1-28.)
Table 3-2

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
