Kyocera FS-1020D User Manual

KM-NET Remote Operation Panel Utility
1-7
1.2 KM-NET Remote Operation Panel Utility
The KM-NET Remote Operation Panel utility is provided on the Kyocera
Mita Software Library CD-ROM supplied with the printer. You can use it to
change basic printer settings, monitor the current printer status, and
display error messages (such as paper jam warnings) on the computer
screen.
1.2.1 Requirements
The KM-NET Remote Operation Panel utility is designed to run under
Windows 95/98/Me or Windows NT 4.0/2000/XP operating systems.
Depending upon which Windows operating system you are using, the
interface connection that can be used with the KM-NET Remote Operation
Panel Utility will differ as follows.
• The KM-NET Remote Operation Panel utility does not run under any
other operating systems.
• The KM-NET Remote Operation Panel utility provided on the Kyocera
Mita Software Library CD-ROM supplied with the printer is for use
only with the Kyocera Mita FS-1020D KX printer driver. Printing
problems may occur if it is used in combination with any other printer
driver.
Interface
Windows
OS
Parallel Serial USB Network
(TCP/IP,
IPX/
SPX)
Windows 95 Yes Yes No Yes
Windows 98 Yes Yes Yes Yes
Windows Me Yes Yes Yes Yes
Windows NT4.0 Yes Yes No Yes
Windows 2000 Yes Yes Yes Yes
Windows XP Yes Yes Yes Yes
Yes
: Useable No : NOT useable
Table 1-3
Note

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
