Printer Configuration
1-13
Enable Traps (unsolicited notifications)
This allows the KM-NET Remote Operation Panel utility to obtain and
display information about the printer, such as the open/closed state of the
top cover, that is output automatically by the network interface card in the
printer. This requires that the network output of status information by the
network interface card be enabled. To do this, click on the Browse NIC Web
Page button to call up SNMP trap notification from the network interface
card homepage.
Polling
With Polling activated (check box checked), the KM-NET Remote
Operation Panel utility logs itself onto the printer and automatically
recognizes printer changes at regular intervals. This duration of the
interval can be configured by moving the slider with the mouse. The
default setting is 5 seconds. Polling must normally be left activated (check
box checked).
Error notification
Each of the following functions are activated when the appropriate check
box is checked.
These settings allow you to determine the way your computer notifies you
of errors:
Audible Notification
A sound is played when an error occurs. Specify the.wav file to be used for
the sound by pressing the button on the right and browsing for the folder
that contains it.
Show on Taskbar
Error notification is given by displaying an icon on the task bar.
Always on top
Error notification is given by a message that is displayed on top of all other
windows that may be currently open on the desktop.
Show on Taskbar
Audible Notification
Always on top
