Kyocera FS-1020D User Manual

Printer Environment
1-37
1.5.5 Sleep Mode
The printer has a sleep timer to conserve power when the printer is not
printing, processing, or receiving data. You can set On or Off of the Sleep
mode. The default setting is On. (See also section 1.5.6 Sleep Time on
page 1-38.)
1
Click the MENU button on the start-up screen.
2
The Menu dialog box appears. Select and double click System.
3
Select and double click Sleep Mode Setting, then click Sleep Mode.
Use the mouse to move the slider on the right side of the screen to
the left or right. You can toggle the sleep mode On and Off using the
radio buttons on the right side of the screen.
4
After you have selected On or Off, click the OK button to return to
the start-up screen. The sleep mode is changed.
System
On / Off
Sleep Mode

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
