Kyocera FS-1020D User Manual

Printer Environment
1-44
1.5.10 RAM Disk
RAM disk enables electronic sorting, which reduces the overall amount of
time required for printing. The default setting is Off.
• Data contained on the RAM disk is lost when the printer is reset or the
power is turned off.
• The RAM disk is set from the printer’s user available memory. Print
speed may be slowed or insufficient memory warnings may occur, if
the RAM disk size is inappropriate, or if the print data is too complex.
1
Click the MENU button on the start-up screen.
2
The Menu dialog box appears. Select and double click RAM disk
mode. Using the radio buttons on the right side of the screen, you
can toggle RAM disk mode On and Off.
Note
RAM disk mode
On / Off

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
