3-218
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
(5) Other optional items for main frame
(5-1) Output(5-1)-Fiery Print Server (Printing System 50)
1
Remove the rear right upper cover [A] in the direction of the arrow (Screw x8). The
screw will use in step 13.
2
Remove the rear lower cover [A] in the direction of the arrow (Screw x9). The screw
will use in step 12.
• All tapes and packing materials on the accessories parts have to be removed.
• Main power switch has to be turned off and power cable has to be unplugged before install Printing System
50.
• See Fiery Print Server (Printing System 50) and Printing System Interface Kit 50 for unpacking.
To Next Page
