COMPONENT MAINTENANCE MANUAL
AVIATION PRODUCTS
Model FA5000
Rev. 02 Page 127
July 21/17
Testing & Fault Isolation
23–70−30
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
(18) OMS
Read the OMS status words and verify CVR fault status and CVR part number and
serial number.
Example report message(s):
08:59:00 PASSED OMS Part 1 (Expected OMS Status to match)
08:59:10 PASSED OMS Part 2 (Expected OMS Part and Serial Numbers to match)
Results = pn2100−1025−22 sn000000000
(19) RIPS
Clear the FA2100 fault log and existing faults that might prevent RIPS test success.
Remove FA2100 recorder power and verify the recorder continues to operate for
over 9 minutes after power is removed.
Example report message(s):
09:00:02 RIPS Initialization (Power has been removed. Please wait 9 minutes)
09:09:15 PASSED RIPS (Expected no CVR Fault for over 9 minutes) Results =
No CVR Fault after power removed for over 9 minutes
(20) FRED
Verify FA2100 Flight Recorder Electronic Documentation (FRED) file exists or can be
written.
Example report message(s):
09:09:30 PASSED FRED – Engineering Units File CRC Verified
(21) FDR
Clear the FA2100 fault log and existing faults that might prevent FDR test success.
Record simulated flight data and verify good flight data was recorded.
Example report message(s):
09:11:00 PASSED FDR Test Results = 1 minute(s) of good data
NOTE
: The Data Link test, OMS test and FDR tests requires a CATS V2 RIU
and rear panel cable.
