COMPONENT MAINTENANCE MANUAL
AVIATION PRODUCTS
Model FA5000
Rev. 02 Page 12
July 21/17
Description and Operation
23–70−30
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
0
1
2
127
126
125
Two 128 Mbit
flash chips
containing 128
128 Kbyte erase
blocks per chip
0
1
2
1023
1022
1021
128 Kbyte erase
block containing
1024 128−byte
pages
Block Header
Spare
Page Header
DataLink
Messages
Each page
contains thirty
32−bit DataLink
messages
32 bytes
32 bytes
8 bytes
120 bytes
3
124
Flash Memory
Chips
Flash Memory
Blocks
Flash Memory
Pages
Figure 6. DataLink Memory Format
