L3 FA5000 User Manual

COMPONENT MAINTENANCE MANUAL
AVIATION PRODUCTS
Model FA5000
Rev. 02 Page 52
July 21/17
Description and Operation
23–70−30
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
915 Second character of serial number
16 Not used 0
1723 Third character of serial number
24 Not used 0
2531 Fourth character of serial number
32 Parity
i. Serial Number (continued)
Bit No Function Status
18 Label 354 11101100
915 Fifth character of serial number
16 Not used 0
1723 Sixth character of serial number
24 Not used 0
2531 Seventh character of serial number
j. Serial Number (continued)
Bit No Function Status
18 Label 354 11101100
915 Eighth character of serial number
16 Not used 0
1723 Ninth character of serial number
2431 Not used 00000000
32 Parity
k. End of Transmission Word
Bit No Function Status
18 Label 354 11101100
924 Not used 0000000000000000
2531 EOT 0000100
32 Parity
C. Label 377 ARINC 429 Equipment Identification Word Output
The CVR outputs a Label 377 equipment identification word on the OMS bus once
per second. The word structure is defined below:
Bit No Function Status
18 Label 377 11111111
910 SDI 00
1118 Equipment ID (CVR = 0x57) 11101010
1929 Not Used
3031 SSM 00
32 Parity
