Lantronix SLC 8048 User Manual

9: Device Ports
SLC™ 8000 Advanced Console Manager User Guide 172
Figure 9-7 Device Ports - Power Management
3. Enter the following:
Power Management
Sequence
A series of one to ten characters that will display the Power Management menu
when connected to the device port. The default value is Esc+P (escape key, then
uppercase "P"). This value is specified as
\x1bP, which is hexidecimal (\x)
character 27 (
1B) followed by a P.
See Key Sequences on page 230 for notes on key sequence precedence and
behavior.
RPM For each managed power supply, select a RPM, most likely a PDU, which has
outlets that can be individually controlled, and which provides power to the device
connected to the device port.

Lantronix SLC 8048 Specifications

General

Ports	48
Management	Web-based, SNMP, CLI
Layer	Layer 2
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
Console Ports	1 (RJ-45)
Protocols	TCP/IP, SNMP
Dimensions	440 x 260 x 44 mm
Storage Temperature	-20°C to 70°C
