15: Command Reference
SLC™ 8000 Advanced Console Manager User Guide 410
show usb storage
Description
Display product information and settings for any USB thumb drive.
Syntax
show usb storage
show usb
Description
Display currently attached USB devices with product information and settings.
Syntax
show usb
show usb modem
Description
Display product information and settings for any USB modem:
Syntax
show usb modem
USB Modem Commands
set usb modem
Syntax
set usb modem <u1|u2> <parameters>
Parameters
auth <pap|chap>
baud <300-115200>
9600 is the default.
calleridcmd <Modem Command String>
calleridlogging <enable|disable>
cbcpnocallback <enable|disable>
cbcptype <admin|user>
chapauth <chaphost|localusers>
chaphost <CHAP Host or User Name>
checkdialtone <disable|5-600 minutes>
databits <7|8>
