Lenze 8200 vector Mounting Instructions

Technical data
2
EDK82EV113 DE/EN/FR 8.1
91
L
Normes et application conditions
Standards
Conformity CE Low−Voltage Directive (73/23/EEC)
Approvals UL 508C Power Conversion Equipment (File−No. E132659)
Environmental conditions
Climatic conditions
Storage IEC/EN 60721−3−1
1K3 (−25 ... +60 °C) < 6 month
1K3 (−25 ... +40 °C) > 6 month
> 2 years: anodizing of DC−bus
capacitors
Transport IEC/EN 60721−3−2 2K3 (−25 ... +70 °C)
Operation IEC/EN 60721−3−3 3K3 (−10 ... +55 °C)
8200 vector 15 ... 90 kW: 3K3 (−10 ... +50 °C)
Power derating above +40 °C: 2,5 %/°C
Installation height 0 ... 4000 m amsl
Power derating at 1000 ... 4000 m amsl: 5 %/1000 m
Pollution EN 61800−5−1 Degree of pollution 2
Vibration resistance Germanischer Lloyd General conditions: acceleration resistance up to 0.7g
Application conditions
Mounting positions vertical
Free space
above/below 100 mm
to the sides Side−by−side mounting with a distance of 3 mm
Max. permissible motor cable
length
For rated mains voltage and chopper frequency of 8 kHz without additional output filters
shielded 50 m
For compliance with EMC regulations,
the permissible cable lengths must be
changed
unshielded 100 m
DC group drives possible, except E82xV251K2C und E82xV371K2C
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Lenze 8200 vector Specifications

General

Category	DC Drives
Series	8200 vector
Enclosure Rating	IP20
Control Method	Vector control
Communication	CANopen, DeviceNet, Profibus
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Humidity	< 95 % non-condensing
Operating Temperature	0 to +45 °C (derating above 40°C)
