11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 173

Ethernet Port
Connector type .............................................................................
Ethernet data rate .......................................................................... 
Power over Ethernet (PoE) ..........................................................................................................Not supported
Ethernet protocol .....................................................................................................
Alarm Output
Connector type ...................................................................................................... SMPTE 269M standard BNC


device and the softwares:
Purpose/function
Affected
software
Protocol Port nr.
Device Discovery LDC UDP 224.0.0.251:5353
Remote IP LDC UDP 230.76.87.82:37421
 - TCP 10001
HTTP port - TCP 80
Factory Default Settings
Network Settings
IP address 192.168.254.254
Subnet mask 255.255.0.0
Static gateway 0.0.0.0
DHCP Disabled
 10001
HTTP Port number 80
Control protocol 
Video Port Settings
Crosspoint state I1 input port on all output ports
 Unmuted, Unlocked
Emulated EDID (input ports) F49 – Universal HDMI EDID
EDID memory Empty (User and Dynamic EDIDs)
Crosspoint presets All outputs to I1
Preset names Preset1, Preset2,...
Port names Input1, Input2...; Output1, Output2...
RS-232 Settings
Baud rate 57600
Databits 8
Parity No
Stopbits 1
Control protocol 




