Lightware MX-FR Series User Manual

4. Operation MX-FR Series Modular Matrix Frames – User's Manual 53

Menu Structure
Normal mode
IP settings
IP status
DHCP enable [-]
Port
IP address
IP gateway
IP subnet
Save & Exit
RS-232 settings
Baud rate
Protocol settings
LAN
RS-232
Input settings
Output settings
Hardware status
Router status
Card information
Firmware versions
Factory reset
IP reset
I/O card reset
EDID reset
HDCP key reset
Protocol reset
All reset
HDCP keycounter
View log...
Switch In## Out## / Input #80
Config backup
EDID management (mode)
View EDID
Dynamic EDIDs
Emulated EDIDs
Factory EDIDs
User EDIDs
Save EDID
Switch EDID
Signal present (mode)
Test input
Preview output
Crosspoint
Crosspoint status
Normal Mode
The Up ▲ and down ▼ buttons select between menu items. More items
become visible when scrolling down. The Enter  or right ► buttons step
in submenus.
IP Settings Menu
This menu contains the IP status submenu, DHCP enable checkbox and TCP/
IP port value. If the DHCP is switched off, then IP address, Default gateway
and Subnet mask can be set as well. Changes take place only when Save
settings is executed. Press the escape  button to return to the main menu
without saving any changes.
IP Status Submenu
Navigate to this submenu and press the enter  or right ► buttons to see
the current IP address, port, gateway and subnet mask. No changes can
be made in this submenu. Press escape  to return to the previous menu.
 #dhcp
Navigate to this item with the up ▲ and down ▼ buttons. Pressing enter 
toggles the DHCP state. If DHCP is inactive then the IP address, Gateway,

Port Value
Navigate to this item with the up ▲ and down ▼ buttons. Use the left ◄ and
right ► buttons to change the TCP/IP port value.
#ipaddress #network
IP Address Submenu
Navigate to this item with the up ▲ and down ▼ buttons. This submenu
appears only if DHCP is disabled. Press the enter  or right ► button to
step in.
left ◄
and right ► buttons to select the part, and then use the up ▲ and down
▼ buttons to change the value of that part. Press the escape  button to
return to the previous menu.
Default Gateway Submenu
This submenu can be used the same as the IP address submenu.
Subnet Mask Submenu
This submenu can be used the same as the IP address submenu.
~IP settings >>
RS-232 settings
Protocol settings
Input settings
~IP settings >>
IP SETTINGS
~IP status >>
DHCP enable [*]
Port
IP: 192.168.002.105
Port: 10001
GW: 000.000.000.000
SM: 255.255.255.000
IP SETTINGS
IP status
~DHCP enable [*] ~
Port
PORT SETTING
Port number
~ 10001 ~
-
IP SETTINGS
DHCP enable [ ]
Port
~IP address >>
IP SETTINGS
IP address
~192.168.002.102 ~
---




