D9U004GKC-0101
25
6 Technical specication
All technical data are rated data are subject to construction and manufacturing tolerances.
6.1 Identication of Applied Parts (Type B)
All part of the chair (and accessories) the patient can reach are type B Applied Parts.
■ upholstery/mattresses
■ footrests
■ leg holders
6.2 Mechanical Specications (Graciella)
Parameter Value
Maximum chair length (without footrests) 1325±10mm
Maximum chair length (with footrests) 1733±10mm
Maximum chair length (with Goepel-footrests) 1402±10mm
Maximum chair length (with double-joint Goepel footrests) 1495±10mm
Overall width (across footrests) 780 - 845 mm
Upholstery width (max.) 630±5 mm
Upholstery thickness 30±2 mm
Height of the seat of the chair — in sitting position 615±5 mm
Maximum height of the seat of the chair (front edge) 1043±5 mm
Adjustment angle of the backrest part to seat part 0°±2°/+40°±2°
Adjustment angle of the seat part 0°±2°/+20°±2°
Trendelenburg position -12°±2°
Footstep above ground min. 275 - 540 mm
Patient load 180 kg
Maximum chair load 195 kg
Permissible footrest load 32 kg
Chair weight (depending on conguration) 85 - 115 kg
Permissible bowl load 2.4 kg
Maximum load of Eurobar 10 kg
Volume of hanging bowl 2.4 l
Protection IPX4
Foot controller protection IPX6
Mode of operation Int. 2/18 min
Noise level Less than 48 dB (A)
Package size l 1922 x w 1024 x h 1117 mm
