D9U004GKC-0101
59
13.1 Step L
13.2 Step R
13.3 Eurobar L
13.4 Eurobar R
Serves for patient step on. In the inactive position, it is located on the right side of the chair.
WARNING!
Take extra care when getting on and off the step. The step is covered with
anti-slip foil.
► When turning the step, beware of collisions with accessories (eg tool table, foot
controller, colposcope holder).
► Cannot be combined with the colposcope holder for the left side.
► The maximum load is 180 kg.
Serves for patient step on. In the inactive position, it is located on the left side of the chair.
WARNING!
Take extra care when getting on and off the step. The step is covered with
anti-slip foil.
► When turning the step, beware of collisions with accessories (eg tool table, foot
controller, colposcope holder).
► Cannot be combined with the colposcope holder for the right side.
► The maximum load is 180 kg.
Used to place accessories, such as an infusion stand.
WARNING!
The maximum load – see technical data.
► Please ensure that when moving the chair up and down, the surrounding
objects are not caught, or persons captured by the eurobar.
► The maximum static load is 16 kg.
Used to place accessories, such as an infusion stand.
WARNING!
The maximum load – see technical data.
► Please make sure that it does not get caught when moving the chair up and
down are not caught, or persons captured by the eurobar.
► The maximum static load is 16 kg.
Manipulation:
► When disassembling, first unscrew the rose from the back of
the step.
Manipulation:
► When disassembling, first unscrew the rosette from the back
of the step.
