D9U004GKC-0101
51
12.1 Footrests - without vertical adjustment
Manipulation:
► Insert the support into the holder and secure it from below with a rosette
► Movement of the arm from the centre / to the centre of the chair:
■ grab the footrest arm
■ slightly loosen the rosette
■ adjust the footrest to the desired position
■ retighten the rosette
■ make sure that the Goepel arm is held rmly
Replacement for Goepel
(if both variants are ordered as part of the chair)
(footrests / footrests Goepel)
■ grab the footrest
■ unscrew the lower rose
■ remove the footrest from the holder
■ set the footrest aside
■ grab the Goepel
■ insert the Goepel into the holder
■ screw in the lower rose
make sure the Goepel is held firmly
WARNING!
► Improper handling can cause injury to the patient, or operator!
► The footrests are not intended for stepping and leaning the body - there is a risk of instability of the chair
► The footrests are intended to support the feet when the patient is sitting / lying down
► Always make sure that the supports are sufficiently secured before use
► Each support can be loaded with weights of 16 kg / 35 lb
► In the event of an overload, the support will drop - immediately relieve the support - there is a risk of damage
► When handling the chair (moving downwards) take extra care to avoid collisions with surrounding objects (eg.
chair)
