D9U004GKC-0101
52
12.2 Footrests - electrically operated
Manipulation:
► Insert the support into the holder and secure it from below with a rosette
► Movement of the arm from the centre / to the centre of the chair:
■ grab the footrest arm
■ slightly loosen the rosette
■ adjust the footrest to the desired position
■ retighten the rosette
■ make sure that the Goepel arm is held rmly
► Movement of the arm up / down
■ The movement is performed using the buttons on the hand controller
intended for the movement of the footrests
Replacement for Goepel
(if both variants are ordered as part of the chair)
(footrests / footrests Goepel)
■ grab the footrest
■ unscrew the lower rose
■ remove the footrest from the holder
■ set the footrest aside
■ grab the Goepel
■ insert the Goepel into the holder
■ screw in the lower rose and make sure that the Goepel
is held firmly
WARNING!
► Improper handling can cause injury to the patient, or operator!
► Footrests are not intended for stepping and leaning the body - there is a risk of instability of the chair
► The footrests are intended to support the feet when the patient is sitting / lying down
► Always make sure that the supports are sufficiently secured before use
► Each support can be loaded with weights of 16 kg / 35 lb
► In the event of an overload, the support will drop - immediately relieve the support - there is a risk of damage
chair
► In the event of an impact from below, the support will be raised - immediately stop moving downwards - there is
a risk of instability of the chair
► When handling the supports take extra care - risk of collisions with surrounding objects (eg. chair)
► When handling the chair (moving downwards) take extra care to avoid collisions with surrounding objects (eg.
chair)
