D9U004GKC-0101
28
Table 1 – Electromagnetic immunity, telecommunication services according to IEC 61000-4-3
Test frequency
(MHz)
Band
(MHz)
Service Modulation Immunity test level
V/m
385 380 - 390 TETRA 400 Pulse modulation 18 Hz 27
450 430 - 470 GMRS 460, FRS 460 FM ± 5 kHz deviation
1 kHz sine wave
28
710
745
780
704 - 787 LTE band 13, 17 Pulse modulation
217 Hz
9
810
870
930
800 - 960 GSM 800/900, TETRA
800, iDEN 820, CDMA
850,
LTE band 5
Pulse modulation 18 Hz 28
1,720
1,845
1,970
1,700 - 1,990 GSM 1800; CDMA
1900; GSM 1900;
DECT; LTE band 1, 3,
4, 25; UMTS
Pulse modulation
217 Hz
28
2,450 2,400 - 2,570 Bluetooth, WLAN,
802.11 b/g/n, RFID
2450,
LTE band 7
Pulse modulation
217 Hz
28
5,240
5,500
5,785
5,100 - 5,800 WLAN 802.11 a/n Pulse modulation
217 Hz
9
NOTE No deviations from the requirements of the standard are applied to EMC.
NOTE No other measures are known to maintain basic safety in terms of EMC.
NOTE Chairs equipped with a communication module work as standard IEEE 802.11 b/g/n (2 400 to 2 483,5 MHz, modulation
DSSS (IEEE 802.11 b ), OFDM (IEEE 802.11 g/n) 20MHz bandwidth EIRP = 0.34 W.
7 Use and Storage Conditions
DANGER!
Danger to life due to electric shock!
To ensure the chair’s class I protection against electric shocks:
► Ground the mains.
► Use exclusively Hospital Grade or Hospital Only receptacles for grounding.
Graciella Chair is designed for use in rooms for medical purposes. Electrical installations must therefore meet local norms laying
down the necessary conditions for electrical installations.
► Disconnect the chair from the mains in exceptional cases (i.e. lightnings, earthquake).
Graciella Chair is not suitable for indoor environments containing ammable gases (except oxygen cylinders).
