D9U004GKC-0101
49
11.2.11 Trendelenburg emergency position adjustment using the backrest and
seat section adjustment buttons
To position Emergency Trendelenburg Position use:
► Hand controller, foot controller
Trendelenburg position is suitable if the patient is in shock.
During Trendelenburg Position the lying area is straightened in the tilt.
1) Use the downward adjustment button to set the backrest to the lower end position
2) Use the seat adjustment button upwards to set the seat to a position of approx. 12° (short acoustic signalization)
Fig. Trendelenburg Emergency Position/Trendelenburg Tilt
Operator´s Manual Control Panel:
► Press the Trendelenburg tilt button, until intended position is reached.
Fig. Backrest adjustment button
(Manual controller, Foot controller).
1. Backrest upwards
2. Backrest downwards
Fig. Sitting section adjustment button
(Manual controller, Foot controller)
1. Seat section upwards
2. Seat section downwards
1
2
1
2
