Linksys LAPN300 User Manual

Network setup
Configure basic device settings, VLAN settings and settings for the LAN
interface, including static or dynamic IPv4/IPv6 address assignment.
Figure 14: Network Setup Screen
Network Setup Screen
TCP/IP
Host Name Assign a host name to this access point. Host name
consists of 1 to 15 characters. Valid characters include A-
Z, a-z, 0-9 and -. Hyphen character cannot be first and last
character of hostname and hostname cannot be composed
of all digits.
VLAN Enables or disables VLAN function. Workgroup Bridge can
only be enabled when VLAN function is disabled.
Untagged
VLAN
Enables or disables VLAN tagging. If enabled (default),
traffic is untagged when VLAN ID is equal to Untagged
VLAN ID and untagged traffic can be accepted by LAN port.
If disabled, traffic from the LAN port is always tagged and
only tagged traffic can be accepted from LAN port.
By default all traffic on the access point uses VLAN 1, the
default untagged VLAN.
23

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
