Linksys LAPN300 User Manual

Additional HTTP
Port
HTTP portal authentication uses the HTTP
management port by default. You can configure an
additional port for that process.
HTTP Port
Define an additional port for HTTP protocol. The value
can be 80 or 1024 to 65535 and is 80 by default. If
Additional HTTP Port is enabled, the HTTP Port must
be different from the HTTP port in "Administration" ->
"Management Access" page.
Additional HTTPS
Port
HTTPS portal authentication uses the HTTPS
management port by default. You can configure an
additional port for that process.
HTTPS Port
Define an additional port for HTTPS protocol. The
value can be 443 or 1024 to 65535 and is 443 by
default. If Additional HTTPS Port is enabled, the
HTTPS Port must be different from the HTTPS port in
"Administration" -> "Management Access" page.
Portal Profiles
Define detailed settings for Captive Portal profile. Create up to two profiles.
Figure 34: Portal Profiles
55

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
