Linksys LAPN300 User Manual

Chapter 3 – System Status
System Summary
Provides the system status of the access point.
Figure 40: System Summary Screen
System Summary Screen
System Summary
Device SKU
The SKU is often used to identify device model number and region.
Firmware Version
The version of the firmware currently installed.
Firmware
Checksum
The checksum of the firmware running in the access point.
Local MAC
Address
The MAC (physical) address of the wireless access point.
Serial Number
The serial number of the device.
Host Name
The host name assigned to the access point.
System Up Time
How long the system has been running since the last restart or reboot.
System Time
The current date and time.
Power Source The power source of the access point. It can be Power over Ethernet
(PoE) or Power Adapter. When two power sources are plugged in, PoE
has higher precedence.
Buttons
Refresh
Click to update the data on the screen.
63

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
