Linksys LAPN300 User Manual

Wireless Status
Wireless Status displays settings and status of the wireless radio and SSID.
Figure 42: Wireless Status Screen
Wireless Status Screen
Radio Status
Radio Status
Indicates whether the radio is enabled.
Mode
Current 802.11mode (a/b/g/n) of the radio.
Channel
The channel currently in use.
Channel
Bandwidth
Current channel bandwidth of the radio.
When set to 20 MHz, only the 20 MHz channel is in use.
SSID Status
Interface
SSID index.
SSID Name
Name of the SSID.
Status
Status of the SSID, enabled or disabled.
MAC Address
MAC address of the SSID.
VLAN ID
VLAN ID of the SSID.
Priority
The 802.1p priority of the SSID.
66

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
