Linksys LAPN300 User Manual

Profile Association
Associate defined Captive Portal profiles with SSIDs.
Figure 38: Profile Association
Profile Association Screen
SSID A list of available SSIDs.
SSID Name The name of the SSID.
Profile Name Choose the profile that is associated with the SSID.
If the profile associated with the SSID is deleted, then
the association will be removed.
If None is selected, it means no profile is associated.
61

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
