Linksys LAPN300 User Manual

Appendix A - -- Troubleshooting
Overview
This chapter covers some common problems encountered while using the wireless access point, and
some possible solutions to them. If you follow the suggested steps and the wireless access point still
does not function properly, contact your dealer for further advice.
General Problems
Problem 1: I can't find the access point on my network.
Solution 1: Check the following:
Make sure the wireless access point is properly installed, LAN
connections are OK, and it is powered on. Check the LEDs for
system and port status.
Ensure that your PC and the wireless access point are on the
same network segment. (If you don't have a router, this must be
the case.)
You can use the following method to determine the IP address of
the wireless access point, and then try to connect using the IP
address, instead of the name.
To find the access point's IP address:
Open a MS-DOS Prompt or Command Prompt Window.
Use the Ping command to ping the wireless access point. Enter
‘‘ping’’ followed by the default name of the wireless access point.
The default name is a string with ‘‘lap’’ and the last 5 characters
of device MAC address; e.g., ping lap964f4.
Check the output of the ping command to determine the IP
address of the wireless access point, as shown below.
81

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
