Linksys LAPN300 User Manual

Rate Limit
Limit downstream and upstream rate of SSIDs.
Figure 28: Rate Limit Screen
Rate Limit Screen
Rate Limit
SSID The index of SSID.
SSID Name The name of the SSID.
Upstream
Rate
Enter a maximum upstream for the SSID. The range is from
0 to 200 Mbps; 0 means no limitation. Upstream is for traffic
from wireless client to access point.
Downstream
Rate
Enter a maximum downstream for the SSID.
The range is
from 0 to 200 Mbps; 0 means no limitation. Downstream is
for traffic from access point to wireless client.
42

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
