Linksys LAPN300 User Manual

Radius Authentication
Primary Server Enter the IP address of the RADIUS Server on your
network.
Primary Server Port
Enter the port number used for connections to the
RADIUS Server.
Primary Shared
Secret
Enter the key value to match the RADIUS Server.
Backup Server The Backup Authentication Server will be used when
the Primary Authentication Server is not available.
Backup Server Port
Enter the port number used for connections to the
Backup RADIUS Server.
Backup Shared
Secret
Enter the key value to match the Backup RADIUS
Server.
Password Only Authentication
Password
The password for the profile. Wireless clients only
need one password to access the wireless network.
Local User
Configure user settings for Captive Portal. Local users are used to do local authentication for Captive
Portal. Up to 128 users are supported.
Figure 35: Local User
57

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
