Linksys LAPN300 User Manual

LAN Status
LAN Status displays settings, and status of LAN interface.
Figure 41: LAN Status Screen
LAN Status Screen
VLAN
VLAN Enabled or disabled (default).
Untagged VLAN Enabled (default) or disabled.
If enabled (default), traffic is untagged when VLAN ID is equal to
Untagged VLAN ID and untagged traffic can be accepted by LAN port.
If disabled, traffic from the LAN port is always tagged and only tagged
traffic can be accepted from LAN port.
By default all traffic on the access point uses VLAN 1, the default
untagged VLAN.
Untagged VLAN
ID
Displays the untagged VLAN ID. Traffic on the VLAN that you specify
in this field is not tagged with a VLAN ID when forwarded to the
network. VLAN 1 is the default ID for untagged VLAN.
64

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
