Linksys LAPN300 User Manual

SSID Settings
SSID Name Enter the desired SSID Name. Each SSID must have a unique name.
The name includes 1 to 32 characters
Broadcast Enable or disable the broadcast of the SSID.
When the access point does not broadcast its SSID, the network name
is not shown in the list of available networks on a client station.
Instead, you must enter the exact network name manually into the
wireless connection utility on the client so that it can connect.
Isolation Enable or disable isolation among clients of the SSID. If enabled,
wireless clients cannot communicate with others in the same SSID.
Disabled by default.
VLAN ID Enter the VLAN ID of the SSID.
Used to tag packets which are received from the wireless clients of the
SSID and sent from Ethernet or WDS interfaces.
Applicable only when VLAN function is enabled. VLAN function can be
configured in Configuration

LAN

Network Setup screen.
Max Clients Enter the number of clients that can connect to the SSID. The range is
from 0 to 32, and 0 means no limit.
Security settings
Configure security settings of SSIDs to provide data protection over the wireless network.
Figure 17: Security Settings
28

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
