Linksys LAPN300 User Manual

Advanced Screen
Port Settings
Auto
Negotiation
If enabled, Port Speed and Duplex Mode will become grey
and cannot be configured. If disabled, Port Speed and
Duplex Mode can be
configured.
Operational
Auto
Negotiation
Current Auto Negotiation mode of the Ethernet port.
Port Speed Select the speed of the Ethernet port. Available only when
Auto Negotiation is disabled. The option can be 10M, 100M
or 1000M (default).
Operational
Port Speed
Displays the current port speed of the Ethernet port.
Duplex Mode Select the duplex mode of the Ethernet port. Available only
when Auto Negotiation is disabled. The option can be Half
or Full (default).
Operational
Duplex Mode
Displays the current duplex mode of the Ethernet port.
Flow Control
Enable or disable flow control of the Ethernet port.
802.1x Supplicant
802.1x
Supplicant
Enable if your network requires this access point to use
802.1X
authentication in order to operate.
Authentication
This feature supports following two kinds of authentication:
• Authentication via MAC Address
Select this if you want to use MAC address for
authentication.
The access point uses lowercase MAC address for
Name and Password, like xxxxxxxxxxxx.
• Authentication via Name and Password
Select this if you want to use name and password
for authentication.
Name - Enter the login name. The name includes 1 to
63 characters. Special characters are allowed.
Password - Enter the desired login password. The
password includes 4 to 63 characters. Special
characters are allowed.
25

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
