Cleaning and care
26
Cleaning the condenser unit
Check the condenser unit at least
on
ce a year. If the dryer is used
frequently, then clean the condenser
unit on a regular basis.
Always check the fluff filters and the
condenser unit if the Clean out
airways indicat
or light comes on.
Detergent residue, hair and fine fluff
fr
om the dryer can get through the
fluff filters and block the condenser
unit. Dust from the room in which the
dryer is installed can also get into the
condenser unit and cause a blockage.
Removing the condenser unit
 Use
the yellow lever supplied to open
the service panel.
 Inser
t the lever into the middle of the
gap in the top (see arrow) and lever
the panel until it opens at the top.
 No
w remove the panel by pulling it
diagonally upwards. Then place it to
one side.
 T
urn the lever on the inner cover
downwards to the vertical position.
 P
ull the cover forwards.
 The
n remove it by pulling it diagonally
upwards.
 T
urn the lever on the condenser unit
to the vertical position so that the
hook on the lever is no longer in the
groove at the bottom of the
condenser unit housing.

Miele TDA 140 C Specifications

General

Cord length	2 m
Control type	Buttons, Rotary
Loading type	Front-load
Drying system	Condensation
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Cycle time	109 min
Noise level	63 dB
Drying class	-
Drum capacity	7 kg
Current	10 A
AC input voltage	220-230 V
Energy consumption	4.14 kWh
Annual energy consumption	494 kWh

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
Weight	50000 g
Depth with door open	1060 mm
