Miele TDA 140 C User Manual

Installation and connection
41
External condensed water
outlet
Notes
When drying is in progress,
c
ondensed water is pumped into the
condensed water container through
the drain hose which is located at the
back of the dryer.
The condensed water can also be
drained away via the drain hose so that
the condensed water container does
not have to be emptied.
Drain hose length: 1.50 m
Ma
ximum delivery head: 1.50 m
Maximum drain hose length: 4.00 m
The following optional accessories
ar
e available:
– an extension hose,
– a non-return valve kit for connection
t
o an external water outlet. The kit
includes an extension hose.
Arranging the drain hose
 Do not pull on the dr
ain hose
and do not stretch it or allow it to
become kinked.
This could damage the hose.
There will be a small amount of residual
wat
er left in the drain hose. Have a
container ready to collect this.
 P
ull the drain hose off its connection.
 Allo
w any residual water to run into
the container.
 Unwin
d the hose and pull it carefully
out of the holders.

Miele TDA 140 C Specifications

General

Cord length	2 m
Control type	Buttons, Rotary
Loading type	Front-load
Drying system	Condensation
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Cycle time	109 min
Noise level	63 dB
Drying class	-
Drum capacity	7 kg
Current	10 A
AC input voltage	220-230 V
Energy consumption	4.14 kWh
Annual energy consumption	494 kWh

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
Weight	50000 g
Depth with door open	1060 mm
