Miele TDA 140 C User Manual

Problem solving guide
35
Changing the lamp
 Disco
nnect the tumble dryer
from the mains electricity supply.
 Open th
e door.
You will find the interior lamp cover at
the
top of the drum aperture.
 Inse
rt a suitable tool* using light
pressure under the side edge of the
lamp cover as illustrated.
* such as a wide flat bladed screwdriver
 Apply a
little pressure and whilst
doing so turn your wrist in the
direction of the arrow to open the
cover.
The cover will open downwards.
The temperature resistant lamp should
onl
y be ordered from your Miele dealer
or the Miele Spare Parts Department.
 The lamp must be
replaced with
one of the same type and
specification. The lamp specification
and maximum wattage is stated on
the data plate and on the lamp
cover.
 T
urn the lamp anti-clockwise to
remove.
 Replace the lamp.
 T
o close the cover push it upwards
and press it on the left and right until
you hear it click into position.
 E
nsure that it is fitted into
position securely, as any moisture
could cause a short circuit.

Miele TDA 140 C Specifications

General

Cord length	2 m
Control type	Buttons, Rotary
Loading type	Front-load
Drying system	Condensation
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Cycle time	109 min
Noise level	63 dB
Drying class	-
Drum capacity	7 kg
Current	10 A
AC input voltage	220-230 V
Energy consumption	4.14 kWh
Annual energy consumption	494 kWh

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
Weight	50000 g
Depth with door open	1060 mm
