Miele TDA 140 C User Manual

Installation and connection
43
Installation conditions requiring a
non
-return valve
 There is a risk of back-flow into
the dryer if a non-return valve is not
fitted.
Back-flow could damage the dryer
and also
the room in which it is
located.
Certain installation conditions, such
as those
described below, require
the fitting of a non-return valve.
Installation conditions requiring the
fitting of a non-return valve:
– Drainage into a sink or floor gully
wher
e the end of the hose is
immersed in water.
– Connection to a sink drain outlet.
– Connection to a drainage system
alr
eady in use by another appliance,
e.g. a dishwasher or washing
machine.
Maximum delivery head with non-return
valve: 1.00 m
Example: Connection to a sink drain
outlet
The drain hose with non-return valve
fitt
ed can be connected directly to a
suitable sink drain outlet.
 Remove the following from the back
of the dryer at the top: Adapter 1 and
hose clip 3 behind it.

Miele TDA 140 C Specifications

General

Cord length	2 m
Control type	Buttons, Rotary
Loading type	Front-load
Drying system	Condensation
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Cycle time	109 min
Noise level	63 dB
Drying class	-
Drum capacity	7 kg
Current	10 A
AC input voltage	220-230 V
Energy consumption	4.14 kWh
Annual energy consumption	494 kWh

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
Weight	50000 g
Depth with door open	1060 mm
