Miele WTF 130 WPM User Manual

Operating the washer-dryer
17
Examples on how to operate
the machine
Scrolling through a list
The  arrows in the display indicate that
choices are available:
Language 

Touching the  sensor scrolls down the
list to the next option and touching the
 sensor scrolls up the list to the next
option. The OK sensor is used to activ-
ate the option which is currently in the
display.
Identifying options selected
Cap

 
An option which has been activated will
have a tick  next to it.
Setting numerical values
Start in h00:00
The numerical value is highlighted in
white. Touching the  sensor de-
creases the value and touching the 
sensor increases it. The OK sensor is
used to activate the value shown in the
display.
Exiting a sub-menu
Select Back  to exit a sub-menu.
Applications
You can use this washer-dryer to:
– wash separately
Maximum load (depending on pro-
gramme) 7.0 kg;
– dry separately
Maximum load (depending on pro-
gramme) 4.0 kg;
or
– wash and dry in a continuous se-
quence
Maximum load (depending on pro-
gramme) 4.0 kg.

Miele WTF 130 WPM Specifications

General

Door hinge	Right
Control type	Buttons, Rotary
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Half-load	-
Drying capacity	4 kg
Washing capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (wash)	- dB
Water consumption washing per cycle	90 L
Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	- L

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
